Description
*Please note – spec applies to all sizes unless listed separately
- *Frame
-
Size: XS
Alpha Silver Aluminium, curved top tube, internal derailleur and dropper post routing, rack and kickstand mount, 135×5 mm ThruSkewSize: S , M , ML , L , XL
Alpha Silver Aluminium, internal derailleur and dropper post routing, rack and kickstand mount, 135×5 mm ThruSkew - *Fork
-
Size: XS , S
RockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 42 mm offset for 27.5″ wheel, 100 mm QR, 100 mm travelSize: M , ML , L , XL
RockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 46 mm offset for 29″ wheel, 100 mm QR, 100 mm travel
- Hub front
-
Formula DC-20 LW, alloy, 6-bolt, 100×5 mm
- Skewer front
-
116x5mm QR
- Hub rear
-
Formula DC-22LW, 6-bolt, Shimano 8/9/10 freehub, 135×5 mm
- Skewer rear
-
173×5 mm QR
- *Rim
-
Size: XS , S , M , ML , L , XL
Bontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valveSize: M , ML , L , XL
Bontrager Kovee, double-wall, Tubeless-Ready, 32-hole, 23 mm width, Presta valve - *Tyre
-
Size: XS , S
Maxxis Rekon, tubeless ready, EXO casing, folding bead, 60 tpi, 27.5×2.40”Size: M , ML , L , XL
Maxxis Rekon, tubeless ready, EXO casing, folding bead, 60 tpi, 29×2.40” - Rim strip
-
Bontrager TLR
- Shifter
-
SRAM SX Eagle, 12-speed
- Rear derailleur
-
SRAM NX Eagle, 12-speed
- *Crank
-
Size: XS , S , M
SRAM SX Eagle, 30T steel ring, 49 mm chainline, 170 mm lengthSize: ML , L , XL
SRAM SX Eagle, 30T steel ring, 49 mm chainline, 175 mm length - Bottom bracket
-
Truvativ Powerspline, 73 mm, threaded cartridge, 118 mm spindle
- Cassette
-
SRAM PG-1210 Eagle, 11-50, 12-speed
- Chain
-
SRAM SX Eagle, 12-speed
- Pedal
-
VP-536 nylon platform
- Saddle
-
Bontrager Verse Short, stainless steel rails
- *Seatpost
-
Size: XS , S
TranzX JD-YSI34, 100 mm travel, internal routing, 31.6 mm, 350 mm lengthSize: M
TranzX JD-YSI34, 125 mm travel, internal routing, 31.6 mm, 405 mm lengthSize: ML , L
TranzX JD-YSI34, 150 mm travel, internal routing, 31.6 mm, 456 mm lengthSize: XL
TranzX JD-YSI34, 170 mm travel, internal routing, 31.6 mm, 500 mm length - *Handlebar
-
Size: XS
Bontrager alloy, 31.8 mm, 5 mm rise, 690 mm widthSize: S
Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm widthSize: M , ML , L , XL
Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width - Grips
-
Trek Line Comp, nylon lock-on
- *Stem
-
Size: XS , S
Bontrager Comp, 31.8 mm, 7-degree, 35 mm lengthSize: M , ML , L
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm lengthSize: XL
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 60 mm length - Head set
-
Semi-integrated, 1-1/8″
- Brake
-
Shimano MT200 hydraulic disc
- *Brake rotor
-
Size: XS , S , M , ML , L , XL
Shimano RT26, 6-bolt, 160 mmSize: M , ML , L , XL
Shimano RT26, 6-bolt, 180 mm - Brake Set
-
Shimano MT200 hydraulic disc
- Weight
- M – 14.15 kg / 31.2 lbs
- Weight limit
- This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
