Description
RIDING STYLE
Designed for
A more accessible specification, giving the rider a taste of what the powerful Impulso family can do.
Riding Conditions
Riding on paved and unpaved roads with drops of less than 15 cm.
Tech Specs
Frameset
Frame
Disc Brake Specification: Flat Mount 140/160 Bottom Braket Standard: PressFit 86.5
Fork
Bianchi Impulso Integrated Fork Disc Brake Specification: Flat Mount 140/160 Front Axle: thru12 OLD (Over-Locknut-Dimension): 100 mm Tire Clearance: ETRTO 622-42mm Steer tube Diameter: 1 1/8″” Material: Carbon Fiber Composite
Headset
Bianchi Custom Acros ICR (Internal Cable Routing)
Drivetrain
Shifters
Shimano GRX 610 ST-RX610
Rear Derailleur
Shimano GRX 820 RD-RX820 Maximum Cassette Sprocket 36T
Front Derailleur
Shimano GRX 820 FD-RX820
Crankset
Shimano GRX 610 FC-RX610 46-30T Crank Length: 170mm-XS(47)-SM(51), 172.5mm-MD(55)-LG(58), 175mm-XL(61)
Bottom Bracket
Shimano SM-BB72-41B, press fit
Chain
Shimano CN-M7100
Cassette
Shimano CS-HG710-12 speed, 11-36T Driver body Interface: HG11
Brakes
Brakes
Shimano Hydraulic Brake, BR-RX400
Rotor
Shimano SM-RT70 IceTech Hub Interface: Centerlock Rotor Diameter: 160 mm (front&Rear)
Wheels
Wheels
Fulcrum RapidRed 900 2-Way Fit Ready (for clincher and tubeless ready) Rim Diameter: 700C Material: Aluminum Alloy Rim Height: 24 mm Inner Wigth Channel: 22 mm
Tire
Pirelli Cinturato™ GRAVEL H Classic, 40-622 tan sidewall
Cockpit
Stem
Velomann AICR Alloy Rise: -2° Steerer Diameter: 1-1/8″” (28.6mm) HB interface Diameter: 1-1/4″” (31.8mm) Stem Lengths: 80mm –
Handlebar
Velomann Gravel ICR Alloy Flare: 16° Drop: 130mm Reach 70mm Interface Diameter: 1 1/4″” (31.8mm) HandleBar Widths: 400 – SX(47) SM(51), 420 – MD(55) LG(58), 440 -XL(61)
Grips / Extensions
The Spiral Ribbon Cork
Saddle
Seatpost
Bianchi Custom D-Shape Offset: 20mm Back Seatpost lengths: 300mm-SX(47), 350mm- SM(51) MD(55), 380mm-LG(58) XL(61) Material: Epoxy – HM-HS Carbon Fiber Composite
Saddle
Velomann MITORA 149 H1, cover: soft touch, padding: foam, shell: nylon carbon, open shell, Aisi rails, length: 250mm, width: 149mm, weight: 230g ± 2
Based on component availability, Bianchi reserves the right to make changes on specifications without notice.
Geometry
| Impulse (all) | |||||||||||||
| SIZE | TO | B1 | C | D | AND | F | G | G1 | H | THE | X | Y | W |
| XS | 410 | 515 | 425 | 70 | 100 | 592 | 75° | 70.5° | 50 | 391 | 376 | 517 | 1007 |
| SM | 450 | 526 | 425 | 70 | 118 | 600 | 74.5° | 70.5° | 50 | 391 | 378 | 534 | 1014 |
| MD | 490 | 550 | 425 | 70 | 135 | 610 | 74° | 71.5° | 50 | 391 | 391 | 554 | 1025 |
| LG | 520 | 572 | 426 | 70 | 162 | 628 | 73.5° | 71.5° | 50 | 391 | 401 | 580 | 1045 |
| XL | 550 | 600 | 428 | 70 | 190 | 645 | 73° | 72° | 50 | 391 | 414 | 608 | 1064 |
